MOQ: | negotiate |
Price: | negotiate |
Standard Packaging: | cardboard |
Delivery Period: | 16 |
Payment Method: | L/C TT D/P |
Supply Capacity: | 10000pcs |
ITEM | Sandard value | Unit |
Model Number | TXW550039N0-CTP | |
size | 5.5 | Inch |
LCD Type | Normally black | -- |
Drive element | TFT active matrix | -- |
Number of pixels | 720*3RGB(H)X1280(V) | Dots |
Pixel arrangement | RGB stripe | -- |
Pixel Pitch (W*H) | 0.00945(H) *0.0945(V) | mm |
Active area | 68.04(H) * 120.96(V) | mm |
Mechanical OutlineSize(W*H*T) | 76*143.46*2.81 | mm |
Viewing direction | ALL O’CLOCK | - |
LCM Driver IC | ST7703 | - |
LCM interface | MIPI Interface | - |
Lcm pin n count | 25 | |
Backlight leds | 14 | pcs |
Backlight current | 40 | mA |
Backligh voltage | 21 | V |
Cover material | Asahi Glass Tempered Glass | |
Touch screen structure | G+FF | |
ouch Driver IC | GT911 | - |
Touch Interface | IIC | |
Laminating process | OOCA full fit | |
operating temperature | -20+70 | ℃ |
storage temperature | -30+80 | ℃ |
Lumens degrees | 350 | cd/㎡ |
TXWEI is one of the leading tft display manufacturers in China, specializing in the production of tft lcd panels. Our tft lcd display modules are widely used in various industries, such as consumer electronics, automotive, medical, and industrial equipment.
At TXWEI, we understand that every customer has unique requirements for their tft lcd module. That's why we offer customized tft lcd solutions to meet your specific needs. Our experienced team of engineers will work closely with you to design and develop a tft lcd module that perfectly fits your application.
For more information about our customized tft lcd module or to request a quote, please feel free to contact us. Our friendly and professional team will be happy to assist you with all your tft lcd display module needs.
![]() |
