3.2 inch 240 * 320 capacitive touch IPS access control door lock handheld LCD display screen

MOQ: negotiate
Price: negotiate
Standard Packaging: cardboard
Delivery Period: 16
Payment Method: L/C TT D/P
Supply Capacity: 10000pcs
Detail Information
Product Description
Detail Information
Place of Origin
Guangdong,China
Brand Name
TXWEI
Certification
CE ROHS FCC
Model Number
TXW320021S0-CTP
Number Of Pixels:
240*400
Brightness:
350cd/m²
LCD Type:
Normally Black
Viewing Direction:
ALL O’CLOCK
Pixel Pitch (W*H):
55.04*79.7*3.79
Backlight Current:
120
Drive Element:
TFT Active Matrix
Pixel Arrangement:
RGB Stripe
Highlight:

3.2 inch LCD display screen

,

240 * 320 LCD display screen

,

IPS LCD display screen

Product Description

TFT LCD Screen Product Overview


TXW32021S0-CTP is a 3.2-inch full-color TFT touch LCD display screen with a resolution of 240 * 320, an EWV wide viewing angle high-definition capacitive touch screen, operating temperature of -20+70, and display brightness of 350cd/m ².

This product is independently designed, developed, and produced by Shenzhen Tianxianwei Technology Co., Ltd. It provides professional full process technical support services, first-class production quality control, professional after-sales service guarantee, and a complete set of customized development capabilities.

This product is widely used in access control door lock display, handheld display, instrument display, medical equipment display, household appliance display, industrial equipment display, etc.


Features:

  • Product Name: TFT LCD Screen
  • Pixel arrangement: RGB Stripe
  • Pixel Pitch (W*H): 55.04*79.7*3.79
  • Number of pixels: 240*320
  • Operating temperature: -20+70
  • Brightness: 350cd/m²
  • TFT LCD Monitor Screen
  • LCD TFT Display Panel
  • TFT LCD Module


Technical Parameters:

TFT LCD Screen TFT LCD Monitor Screen
Backlight current 120

Touch Driver IC

FT6336U

Touch Interface

IIC
Operating temperature -20+70
storage temperature

-30+80

Touch screen structure

G+F
Number of pixels 240*320
Lcm pin n count 39
IC/LCM Driver IC

ST7789V2

LCM interface

MCU 16 BIT
Pixel Pitch (W*H)5 55.04*79.7*3.79

Active area

48.6*64.8




Product Specifications
  • LCD TFT Display Panel
  • TFT LCD Screen
  • TFT LCD Monitor Screen
  • Lcm pin n count: 39
  • Viewing direction: ALL O’CLOCK
  • Pixel arrangement: RGB Stripe
  • LCD Type: Normally Black
  • Brightness: 350cd/m²







Certification: CE ROHS FCC
With the CE, ROHS, and FCC certifications, this TFT LCD Module is guaranteed to be safe, reliable, and environmentally friendly. These certifications also make it suitable for use in various countries and regions.

Minimum Order Quantity: Negotiate
As a customer-oriented company, TXWEI offers flexible minimum order quantities to cater to the needs of different clients. Whether you need a small or large quantity, we can negotiate and find a solution that works for you.

Negotiate
The price of the TFT LCD Module is negotiable, depending on the quantity and other factors. We strive to provide competitive pricing without compromising on quality, making it a cost-effective solution for your business.
